Filtrimaterjal kvarts FILTER AG (28,3 l kott)
Toode on laos olemas
Tarneaeg: 2-5 tööpäeva
Filter-Ag® is a silica, crystalline quartz media which can be used as highly efficient filter media for the reduction of suspended matter. Its fractured edges and irregular surface provides a high surface area and complex flow path for efficient removal of suspended matter throughout the filter bed, typically reducing suspended solids down to the 20-40 micron range. Filter-Ag®'s larger particle size creates less pressure loss through the filter and allows deeper sediment penetration into the bed for higher sediment loading and longer filter runs.
Clack Filter-Ag® can be applied to systems designed for either pressure or gravity flow. Because of its unique density, Filter-Ag® can also be used in multi-media (graded density) filter designs allowing a more flexible approach to difficult filtration problems.
PHYSICAL PROPERTIES:
- Color: Light grey to near white
- Specific Gravity: 2.25 gm/cc
- Mesh Size: 12 x 30
- Effective Size: 0.67 mm
- Uniformity Coefficient: 1.8
- Hardness: 6 {Mohs scale)
Tootefotod on illustratiivsed. Toote välimus ja konfiguratsioon võivad erineda, ilma et see mõjutaks toote tehnilisi omadusi või funktsionaalsust.
| Parameeter | Väärtus |
|---|---|
| Materjal | Kristalliline kvarts (SiO₂) |
| Värvus | Helehallist peaaegu valgeni |
| Erikaal | 2,25 g/cm³ |
| Graanulite suurus (Mesh) | 12 × 30 |
| Efektiivne graanulisuurus | 0,67 mm |
| Ühtlustegur | 1,8 |
| Kõvadus Mohsi skaalal | 6 |
| Tüüpiline eemaldatavate osakeste suurus | 20–40 µm |
| Pakend | 28,3 l/kott |
| Laius (cm) | Kõrgus (cm) | Pikkus (cm) | Kaal (kg) |
|---|---|---|---|
| 45 | 15 | 63 | 25 |
